- Footprint = 17 cm (approximat)
- Height with head fitted = 48 cm (approximate)
- Food grade materials are used on parts in contact with water
- 5 year warranty
- NSF 44 certified and complies with PED 97/23/EC Directive
- Moulded rubber base for stand alone stability.
- Threads on the vessel neck are made from 30% glass-filled polypropylene for enhanced strength
- Pressure cycle tested 250,000 times to ensure reliability
- Pressure tested to 42 bar – over 4 times the maximum operating pressure
- Lot-coded for traceability and tracking
- Individually packaged to assist storage, handling and transportation
Applications.
- Commercial and residential water.
- Housing Nitrate / Deionisation resins - housing activated carbon or any chemical media used in fish keeping.
- Can be used as a stand alone filter or in series with HMA or Reverse Osmosis filter.
Supplied complete with distribution head. The head is complete with internal screens to prevent resin escaping and your selected inlet / outlet options.
How to Install Vessel
To aid shipping, pressure pod is supplied with the amount of resin if ordered already inside it.
We recommend running your water through the HMA (or RO filter first) and fitting the vessel after.
Fit the John Guest fitting labelled "A" to the inlet port
Fit the John Guest fitting labelled "B" to the outlet port
(Head is marked with an arrow to indicate flow)
Connect a length of tube ( supplied) from the outlet of you HMA / RO to the inlet side of the Nitrate filter. Or if using as "stand alone" from the water supply.
Fit the supplied tube to the outlet side of the filter. Install the blue handled tap (supplied) to this to control water flow and you will need it also for regeneration if using Nitrate resin.
Installation is now complete.
Turn your water on - it may take a little while for water to emerge from the
out let of the Nitrate filter - once water is flowing - check for leeks.
That's it we are done.
Regeneration
Regulary monitor for any nitrate in the product water - as soon as a trace is detected, regenerate the resin. Do not allow the value to increase to tapwater levels.
If you are using vessel for Nitrate removal full instructions for regeneration are shipped with product. If vessel is used for carbon filtration or DI resin, these are disposed of when spent and new media needs too be installed.
